Spark 700

Name: Spark 700
Brand: IBRA ENERGY INDIA PVT. LTD.

Get a Price/Quote

MOQ : 1 Piece

Spark 700 Specification

Voltage
380 V

Plastic Processed
PP, ABS, PET, PVC

Noise Level
<70 dB

Control System
PLC Control

Accuracy
0.01 mm

Model No
Spark 700

Motor Power
7.5 kW

Lubricating System
Automatic Centralized

Power Rating
20 kW

Features
High Efficiency, Precision Control, Low Power Consumption

Drive
Hydraulic

Cooling System
Water Cooling

Frame Type
Rigid Welded Frame

Production Capacity
220 pieces/hour

Frequency
50 Hz

Operating Temperature
5 45C

Machine Type
Spark 700

Connectivity Options
Ethernet, USB

Product Type
Plastic Injection Molding Machine

Technology
Hydraulic

Power Source
Electric

Operating Type
Automatic

Power
20 kW

Pressure
700 bar

Surface Treatment
Painted

Dimension (L*W*H)
3.8 1.5 2.1 m

Weight (kg)
2200 kg

Color
Blue & White

Usage & Applications
Plastic Goods Manufacturing

Min. Mould Thickness
210 mm

Max. Mould Size
690 720 mm

Screw Diameter
62 mm

Clamping Force
7000 kN

WorkingSpeed
16 28 s/cycle

Screw L/D Ratio
22:1

Ejector Stroke
162 mm

Safety Features
Emergency Stop, Safety Gates

Nozzle Pressure
192 MPa

Heater Capacity
7.5 kW

Injection Capacity
820 cm

Pump Motor Power
18.5 kW

Operational Interface
Touchscreen HMI

Environmental Standard
RoHS Compliance

Tie Bar Distance
650 670 mm

Spark 700 Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

About Spark 700

The Spark 700 brings an inestimable combination of classic design and valiant engineering to the competitive world of plastic goods manufacturing. Featuring a substantial injection capacity of 820 cm3 and a rigorous clamping force of 7000 kN, it guarantees precision and reliability. With a modern touchscreen HMI, advanced PLC control, and connectivity options like Ethernet and USB, Spark 700 ensures a seamless, automatic, and highly efficient operation. Procure this machine at competitive pricing, made available with swift markdown deals for manufacturers, dealers, and suppliers across India.

Applications and Features of Spark 700

Ideally suited for both general and specific plastic goods manufacturing, the Spark 700 can process PP, ABS, PET, and PVC with high efficiency. Its valiant performance is enhanced by a rigid welded frame, automatic centralized lubrication, water cooling, and a safety-focused design. This classic machine supports a wide range of applications, ensuring reliable, precision control in every operation and consistently delivering superior results for manufacturers and distributors alike.

Export Markets, Supply Ability & Domestic Reach

Spark 700 stands as a trusted choice for the global market, with major export destinations across Asia, Africa, and the Middle East. Stock is readily available for immediate transportation, ensuring fast delivery and uninterrupted supply. Customers can benefit from competitive sale prices, whether for large-scale exports or domestic procurement. The machine is widely supported in all major domestic markets throughout India, making it a dependable asset for wholesalers, dealers, and distributors nationwide.

FAQ's of Spark 700:

Q: How does the Spark 700 enhance production efficiency in plastic goods manufacturing?

A: The Spark 700 offers high-speed operation with a working cycle of 16-28 seconds, precision control, low power consumption, and advanced features like automatic lubrication and centralized PLC control, all contributing to efficient, reliable production.

Q: What safety features are built into the Spark 700 machine?

A: The Spark 700 includes emergency stop buttons, robust safety gates, and adheres to RoHS compliance, providing reliable protection for operators and ensuring safe, environmentally conscious operations.

Q: Where can Spark 700 machines be procured in India?

A: Spark 700 is available through an extensive network of dealers, distributors, exporters, importers, retailers, suppliers, traders, and wholesalers throughout India, ensuring easy access for buyers.

Q: What types of plastics can the Spark 700 process?

A: This machine is capable of processing a versatile range of plastics, including PP, ABS, PET, and PVC, making it suitable for diverse manufacturing applications.

Q: How does the procurement process work for Spark 700 exports?

A: Potential buyers can connect with authorized exporters and suppliers to place orders. With stock ready for transportation, shipments can be processed promptly to reach international and domestic destinations efficiently.

Q: What are the benefits of the PLC control and touchscreen HMI in day-to-day operations?

A: The PLC control system, combined with the user-friendly touchscreen HMI, provides easy operation, accurate settings, quick adjustments, and improved production consistency for operators.
